[xcrysden] dimensions of the Δn(r) and V parameters

[Мищенко В.Н.]

Good afternoon,

I would like to ask a question related to the dimensions of the Δn(r)
and V parameters, which appear in the XCrySden program (version
xcrysden-1.5.60-bin-semishared) on the Print thermometer image panel
during postprocessing using the file diam8A.pbe.pot.in in the pp.x
program in Quantum Esspreso (version 7.4.1). Attached is the scf.in
input file for my structure, as well as a photocopy of the thermometer
panel with the digital data. To obtain charge distribution and total
potential images, I use the   .xcf file obtained using Quantum Esspreso,
but I did not find any data on the dimensions of the above parameters in
this file.

Could you advise me on a possible solution to this problem?
Sincerely,

Valery Mishchenko

PhD, BSUIR
-------------- next part --------------
An HTML attachment was scrubbed...
URL: <https://mailman.ijs.si/pipermail/xcrysden/attachments/20260224/bcab6469/attachment-0001.htm>
-------------- next part --------------
&inputpp
prefix='diam'
outdir='./'
filplot= 'diam8A-22022026-plot0.pbe.pot',
plot_num=0
/
&plot
nfile=1
filepp(1)='diam8A-22022026-plot0.pbe.pot'
weight(1)=1.0
iflag=3
output_format=3
e1(1)=0.00, e1(2)=0.0, e1(3)=0.0
e2(1)=0.0, e2(2)=0.00, e2(3)=0.0
e3(1)=0.0, e3(2)=0.0, e3(3)=3.35
x0(1)=-0.40, x0(2)=0.20, x0(3)=0.0
nx=50, ny=50, nz=50
fileout='diam8A-22022026-plot0.pbe.pot.xsf'
/
-------------- next part --------------
A non-text attachment was scrubbed...
Name: TermometrChage-22022026.jpg
Type: image/jpeg
Size: 94525 bytes
Desc: not available
URL: <https://mailman.ijs.si/pipermail/xcrysden/attachments/20260224/bcab6469/attachment-0001.jpg>
-------------- next part --------------
 &control
    calculation     = 'scf'
    prefix          = 'diam'
    verbosity       = 'low'
    pseudo_dir      = './'
    outdir          = './'
 !   tprnfor         = .true.
 !   tstress         = .true.
 /
 &system
    ibrav           = 0
    celldm(1)       = 6.64245
    nat             = 23
    ntyp            = 1
    ecutwfc         = 50
    ecutrho         = 300
    occupations     = 'smearing'
    smearing        = 'mp'
    degauss         = 0.01
    nbnd            = 160
!    lspinorb        = .true.
!    noncolin        = .true.
 /
 &electrons
    diagonalization = 'david'
    mixing_beta     = 0.7
    conv_thr        = 1.0d-10
 /
ATOMIC_SPECIES
  C  12.011 C_ONCV_PBE-1.2.upf
CELL_PARAMETERS (alat=  6.64245000)
   1.118450580   0.005398649  -0.078214151
  -0.032591306   1.280343565   0.160551462
  -0.352716649   0.229874779   3.355330044
ATOMIC_POSITIONS (alat)
C               -0.0219466381        0.2439483977        0.1363231014
C               -0.3342622004       -0.1957773354        1.2088426549
C               -0.2354867341        0.8402251883        1.0896947065
C                1.0004896850        1.1518498989        0.0302611141
C                0.2393868857        0.6883296299        0.5998860114
C                0.8012925975        0.4725501394        0.1756592015
C                0.2726761360        0.3002605936        1.1846629103
C                0.5209386230        0.0433259949        0.5731373435
C                0.6601885201        0.9452708441        0.6498711542
C                0.9582764375        0.8400957743        0.3384257764
C                0.3725158996        0.3555020548        0.3253817439
C                0.5212665001        0.0729939798        0.9596946592
C                0.0905917630        0.5933500059        1.0013934949
C               -0.1715681943       -0.0626169841        1.5696107401
C                0.1700446319        0.1174639974        1.5483572833
C                0.3960147445        0.0654032786        1.8857859244
C                0.2416494289        0.0417794955        2.2549058137
C               -0.1425041781        0.0099747821        2.2819593435
C               -0.3462667320       -0.0254585071        1.9378707510
C                0.4385691221        0.0487512116        2.5977173309
C                0.3019963079        0.0776619664        2.9755988145
C               -0.1004838454        0.0566630784        3.0046324405
C               -0.2891513921        0.0336146104        2.6486091439
K_POINTS automatic
6 6 6 0 0 0
